Stationary generator 792 kW AP 1100 B

AP 1100 B power generator – Your energy security

What is the AP 1100 B generator?
The AP 1100 B is a reliable generator with a maximum output of 1100 kVA / 880 kW , ensuring continuous power supply in industrial facilities, logistics centers, hospitals, and large construction sites. It guarantees stable operation even in the most demanding conditions.

Key technical parameters of the AP 1100 B?

• ESP maximum power: 1100 kVA / 880 kW

• PRP rated power: 990 kVA / 792 kW

• Rated current: 1435 A

• Nominal voltage: 400 V

• Frequency: 50 Hz

• Generator: STRATHON ECO 1100 KW, brushless, synchronous

• Generator efficiency: 93%

• Protection class: IP 23

• Insulation class: H

Why choose AP 1100 B?

What makes the AP 1100 B unit stand out?
✅ Reliable engine: BAUDOUIN 12M26G1100 with a power of 978 kW and a capacity of 31.8 l guarantees stable operating parameters.
✅ Modern control: The AMF 25 controller enables automatic start-up and presents operating parameters on a clear LCD screen.
✅ Quiet operation: Thanks to the soundproof housing, the noise level is only 70 dB(A) at a distance of 7 m.
✅ Economical operation: 1200 l fuel tank, fuel consumption 207.1 l/h at full load.

Where is the AP 1100 B best suited?

The AP 1100 B is the ideal backup or primary power supply for:

• industrial and manufacturing plants,

• large construction sites,

• hospitals and medical centers,

• photovoltaic farms,

• data centers and logistics facilities.

What additional options can you choose for the AP 1100 B?

You can configure the unit to suit your needs thanks to:

• external fuel tank,

• differential protection,

• synchronization with other units,

• remote monitoring LAN, RS232-485, GPRS, GSM,

• spark catcher,

• ventilation and exhaust system,

• versions with a different voltage configuration,

• external SZR cabinet (IP54).

What is the operation of the AP 1100 B like?

How to care for the generator?
? Oil and filter change: after 100 hours of operation, then every 500 hours or once a year.
? Coolant: replace every 1000 hours or every 2 years.
? Constant supervision: The AMF 25 controller allows remote monitoring and SMS/email notifications.

What are the warranty conditions for the AP 1100 B?

• Reserve mode: 60 months (or 1000 operating hours).

• Continuous operation: 12 months (or 1000 operating hours).

Ensure uninterrupted power supply – choose AP 1100 B

The AP 1100 B is a guarantee that your business will not be left without power – power, automation and reliability in every situation.

Contact us and request an offer tailored to your needs!
